Wear Resistant Ceramic Particles Epoxy Coating
Classification:
Product Alias:
Wear-resistant ceramic particle glue
Related Downloads
For more information, please contact us directly by phone or email
Product Details
Wear-resistant ceramic particle adhesive by high-performance wear-resistant ceramic particles and modified toughened resin composite wear-resistant corrosion-resistant polymerised ceramic materials. Widely used in the repair of various types of wear parts and in various types of wear-resistant, corrosion-resistant requirements of mechanical equipment surface preparation wear-resistant anticorrosion coating.
Application Scope
Used for large-scale repair and pre-protection of fine particle wear equipment under general load, such as large slurry pumps, impellers, housings, hoppers, etc.
Product Specifications
| Order No. | Product Name | Package |
| SA7526 | Wear-resistant ceramic small particle adhesive | 10KG/Set |
| SA7528 | Wear-resistant ceramic large particle adhesive | 10KG/Set |
Usage Method
1. Surface Treatment: Grind or sandblast to remove dust, oil stains, and rust from the surface of the adhered object, and can be cleaned with a cleaning agent.
2. Glue Mixing: Mix the two components evenly according to the ratio, ensuring consistent color.
3. Glue Application: Evenly apply the prepared coating glue to the surface of the protected object to achieve a certain thickness.
4. Curing: Cure at room temperature for 24 hours or heat to 80°C and maintain for 2 hours for curing.
Product Specification
| Product Name | Model | Weight |
| Wear-resistant ceramic small particle glue | SA7526 | 10kg/set |
| Wear-resistant ceramic large particle glue | SA7528 | 10kg/set |
Quality Certifications
Precautions
1. When the temperature is below 15°C, appropriate heating measures should be taken; otherwise, the curing time should be extended.
2. When the ambient temperature is high or the amount of mixed glue is large, the operating time will be shortened.
Packaging and Storage
1. Packaging Specification: 10kg/set, 20kg/box.
2. This product should be stored in a cool, dry, and sealed environment, with a shelf life of 2 years; transport as a non-hazardous material.
3. This product is non-hazardous, but should not be ingested or come into contact with eyes, and avoid prolonged direct contact with the body.
Parameters
| Brand | BAI-OTT or OEM |
| Main ingredient | Ceramic / Rubber / Steel Plate |
| Model | SA7526 / SA7528 |
| Colour | Black and Grey |
| Density ratio(A:B) | 4:1 |
| Operation time(200 mixing, min) | 4:1 |
| Full curing time(h) | 24 |
| After curing Hardness(Shore)GB/T2411-2008 | 89.0 |
| Tensile strength(Mpa)GB/T6329-1996 | 28 |
| Compressive strength(Mpa)GB/T1041-2008 | 110.0 |
| Shear strength(Mpa)GB/T7124-2008 | 16.0 |
| Working temperature | -60～120 |
| Lead time | Ready to ship in stock |
| MOQ | 20 KG |
| Shelf life | 12 Months |
| Supply capacity | 5000 KG / Month |
| Certification | ISO9001; ISO14001; ISO45001; CE; UPEM |
| Packing | Pallet, wooden case |
| Delivery Time | 50～100 KG, 3-5 days / 200～500 KG, 7-10 days |
